SQ19 Filter Inductor Horizontal Base 2+2 Pins

Common mode choke inductor. 2+2 pins vertical SQ23 coil former. Bobbin Size=28.0mmX14.0mmX25.0mm. Parallel Distance=10.0mm. Pin pitch=18.8mm. Flat wire winding common mode choke coils. We are professional transformer bobbin factory, our bobbins mainly used in high frequency line filters, smoothing choke coil, drive transformer, switching power transformers and chokes.

High current SQ23 inductor. 2+2 pins SQ23 horizontal coil former. Bobbin Size=25.5mmX24.0mmX11.75mm. Parallel Distance=22.5mm. Pin pitch=20.0mm. Flat wire winding common mode choke coils. We are professional transformer bobbin factory, our bobbins mainly used in high frequency line filters, smoothing choke coil, drive transformer, switching power transformers and chokes.

Common mode choke base, 2+2 pin inductor base made of PET material. Base Size=27.8mmX43.2mmX18.0mm. Pin distance=22.9mm. Parallel distance=38.1mm. Inductor made in China, accept custom made inductor and transformers.

EI35 ferrite core bobbin. Double slots EI35 coil former. Parallel distance=20.5mm. Bobbin pin pitch=5.0mm. Bobbin size=29.4mmX24.2mmX31.2mm. We manufacture various HF transformer, CT transformers, bobbins and supply magnetic cores, we can make new bobbin/core tooling to meet special requirements.

Transformer bobbin factory. EI19 vertical transformer bobbin 3+3 pin. Bobbin Size=15mmX13.6mmX14.9mm. Parallel Distance=11.5mm. Pin Pitch=4.8mm. PA66 material bobbin. DIP transformer bobbin. UL REC:94V-0. We can make new bobbin tooling to meet different requirements.

2+2 Pin Inductor Base,Phenolic Material,UL REC:94V-0 Base Outside Diameter=10mm, Base Height=3.2mm

4+4 Pins Horizontal Bobbin,EPC10 transformer bobbin,UL REC:94V-0. LCP-E4008 Material,Pin Pitch=2mm Parallel Distance=7.9mm.  Size=11.4mmX10.7mmX4.6mm.

SMPS transformer EE22 coil former. 6+6 pin EE22 vertical transformer frame. Bobbin Size=25.9mmX17.6mmX23.8mm. Parallel Distance=12.5mm. Pin pitch=4.0mm. We have over 10 years in producing various transformer bobbins, we have many type bobbin toolings. We manufacture final high frequency transformers for power supply.

ER35 through hole bobbin, 6+6 pins vertical coil former, bobbin size=30.2mmX28.5mmX40.5mm, pin distance=5.0mm, parallel distance=22.5mm. Phenolic material ER35 electronic transformer bobbin. We manufacture final electronic transformer for power suppliers, low magnetic leakage and good performance, welcome customized transformers.

PQ32/25 power transformer. 6+6 pins vertical PQ32 coil former. Bobbin Size=34.2mmX32.0mmX27.4m. Pin pitch=5.0mm, parallel distance=30.5mm, Phenolic PQ32 bobbin for high frequency transformer, accept custom made and OEM service.

EI19 vertical inductor bobbin. EI19 5+5 pins transformer bobbin. Bobbin Size=20.2mmX16.4mmX16.2mm. Parallel Distance=13mm. Pin Pitch=5mm. DIP transformer bobbin. UL REC:94V-0. We can make new bobbin tooling to meet different requirements.

Flyback transformer EF25 bobbin. 5+5 pin vertical EF25 multi section coil former. Bobbin Size=23.6mmX20.0mmX27.6mm. Pin pitch=5.0mm. Parallel Distance=15.6mm. EF25 double slots coil bobbin. Custom EF25 bobbin tooling, EF25 bobbin datasheet. bobbin catalog, accept small order.
