2+2 pins SQ19 inductor base, horizontal ET coil former for common mode choke inductor. Size=24.0mmX14.3mmX12.5mm. Parallel Distance=10.0mm. Pin pitch=19.0mm. PET material base. We are professional bobbin factory, we have made different series bobbin moldings, samples are available.
brand:
MCTitem no.:
MCT-SQ1903 (H2+2P)shipping port:
Shanghaipayment:
T/T in advanceHot selling common mode choke base, SQ19 bobbin horizontal 2+2 pins, samples can be sent for testing.
Product Specification
For more details, welcome to contact us:
Email: sales003@mycoiltech.com
Skype: sales003_125
Contact: Miss Lily
Vertical High Current Inductor SQ23 Bobbin
Common mode choke inductor. 2+2 pins vertical SQ23 coil former. Bobbin Size=28.0mmX14.0mmX25.0mm. Parallel Distance=10.0mm. Pin pitch=18.8mm. Flat wire winding common mode choke coils. We are professional transformer bobbin factory, our bobbins mainly used in high frequency line filters, smoothing choke coil, drive transformer, switching power transformers and chokes.
SQ23 Common Mode Choke Inductor Bobbin
High current SQ23 inductor. 2+2 pins SQ23 horizontal coil former. Bobbin Size=25.5mmX24.0mmX11.75mm. Parallel Distance=22.5mm. Pin pitch=20.0mm. Flat wire winding common mode choke coils. We are professional transformer bobbin factory, our bobbins mainly used in high frequency line filters, smoothing choke coil, drive transformer, switching power transformers and chokes.
Switch Mode Transformer EF20 Vertical Coil Bobbin
High frequency EF20 bobbin. EF20 4+4 pins coil former. Bobbin Size=19.5mmX13.7mmX19.0mm. Pin pitch=5.0mm. Parallel Distance=10.16mm. EF20 transformer with phenolic bobbin. We can make new tooling to meet customer's design.
EF20 Transformer Two Slots Horizontal Bobbin
Ferrite core transformer bobbin. EF20 horizontal bobbin with two slots. Bobbin Size=20.8mmX20.7mmX14.6mm. Pin pitch=5.0mm. Parallel Distance=15.0mm. EF20 transformer DIP bobbin. We can make new tooling to meet customer's design.
ER28 PCB Mount Transformer Horizontal Bobbin 6+6 Pins
Horizontal bobbin for ER28 ferrite cores. Pin Pitch1=3.7mm. Pin Pitch2=7.5mm. Parallel distance=25.4mm. 6+6 pins ER28 phenolic bobbin. Bobbin Size=29.6mmX29mmX20.8mm. We can make bobbin tooling. DIP bobbin. UL REC:94V-0
EF25 Gate Transformer Two Slot Bobbin
Double slot vertical EF25 bobbin, high frequency bobbin 5+5 pins. Parallel Distance=12.7mm. Pin distance=5.13mm. Bobbin Size=23.9mmX16.5mmX24.8mm. Flyback transformer EF25 bobbin with PA66 PET FR530 material. We can make new EF25 bobbin tooling to meet special size bobbin.
250VAC 100A Shielding Feedthrough Capacitors EMI Filter
Feedthrough EMI filter for shielded rooms. Feedthrough capacitors offer a high insertion loss across a broad band of frequencies from a few tens of kHz up to the GHz region. High quality and reliability. Mainly for power supplies, switching and cellular equipment, computer servers, etc.
ETD49 Transformer Core Stainless Steel Clamps
High voltage trasnformer, ETD49 bobbin clips factory. We manufacture high frequency transfromers and inductors. We make new bobbin tooling to meet special size requirements.
EE55 Power Transformer Bobbin No Pins
EE55/21 ferrite core bobbin, no pin EE55 coil former. Bobbin Size=43.6mmX37.1mmX42.25mm. PET material EE55 transformer bobbin. We are bobbin factory and provide custom bobbin tooling service.
Bobbin Ferrite Core Common Mode Choke Inductor Base
2+2 Pins Dip Base,LCP Material,UL REC:94V-0 Pin Pitch=4.5mm Parallel Distance=14mm Inductor base size=20.5mmX16mmX11.5mm
EF25 L Pin Transformer Bobbin Pin 5+5 Horizontal
Horizontal L pins coil bobbin. EF25 5+5 pins coil former. Bobbin Size=26.2mmX25.6mmX20.5mm. Parallel Distance=15.0mm. Pin pitch1=4.0mm. Pin pitch2=5.0mm. PA66material transformer bobbin.
5+5 Pins EI16 Vertical Transformer Bobbin Dip Bobbin
5+5 Pins Vertical Bobbin,Phenolic Material,UL REC:94V-0 Pin Pitch=3.25mm Parallel Distance=10.5mm Size=16mmx13mmx15mm
